Amerimation Aluminum Switch Boxes

Triangular side

Eagle Sensors & Controls is an authorized Amerimation distributor. Contact us with application and sales support.

① Material

S Square side
T Triangular side

② Number of hole

01 1 hole
02 2 holes
03 3 holes
04 4 holes
05 5 Holes
X X holes (optional)



Dimensions

Number of holes L P
1 3.4in (86mm) –
2 5.4in (136mm) 2in (50mm)
3 7.3in (186mm) 3.9in (100mm)
4 9.3in (236mm) 5.9in (150mm)
5 11.3in (286mm) 7.9in (200mm)
