Tempco Tape Construction

/Tempco/Data-Assets/09-Flexible-Images/Web0519-23.jpg

Silicone Heating Tape

Operating Temperature Range: −100°C to 250°C, −148°F to 482°F

Outgassing…TML/VCM: 1.047%/.322%

Adhesion to Etched Aluminum (oz/inch width): 28 @ +125°C, 450 @−100°C

Overall Thickness Applied: .025″ (.63 mm)

Dielectric Strength: 600 Vdc

/Tempco/Data-Assets/09-Flexible-Images/Web0519-21.jpg

Acrylic Heating Tape

Operating Temperature Range: −100°C to 180°C, −148°F to 356°F

Outgassing…TML/VCM: .264%/.000%

Adhesion to Etched Aluminum (oz/inch width): 29 @ +125°C, 50 @−100°C

Overall Thickness Applied: .028″ (.71 mm)

Dielectric Strength: 600 Vdc
