Amerimation MS66 Series
Eagle Sensors & Controls is an authorized Amerimation distributor. Contact us with sales and technical support.
Key Features
- Steady/Flashing type, Rotating type
- Rotating speed is adjustable
- Direct or Pole Mounting
① Mounting Option
| M |
Body direct mount – Plastic M20 Screw |
| P |
Pole Mounting |
| G |
Plastic mount base |
|
② Light Style
| F |
LED Steady + Flashing |
| B |
LED Steady + Flashing + Audible Alarm |
| R |
LED Rotating |
|
③ Power Supply
| 00 |
12 ~ 24VAC/DC |
| FF |
110 ~ 220VAC(50/60Hz) |
|
④ Lens colors
| R |
Red |
| Y |
Yellow |
| G |
Green |
| B |
Blue |
| C |
Clear |
|
⑤ Optional
| (V) |
Flashing Emergency Signal (*Flashing rate: 240±5 times/min) |
|
Specifications
| Functions |
Steady + Flashing + Buzzer, Rotating + Buzzer |
| Power supply |
12~24VAC |
110~220VAC |
| Current Consumption |
Steady & Flashing |
General |
0.30A |
0.03A |
| w/buzzer |
0.32A |
0.04A |
| Rotating |
General |
0.20A |
0.03A |
| w/buzzer |
0.22A |
0.03A |
| Flashing Rate |
General type |
80 ±5 times/min |
| Optional (V) type |
240 ±5 times/min |
| Rotating Speed |
60~300 RPM (Clockwise rotation) |
| Alarm sound level |
80±5dB (Alternating Buzzer: pi- pi- pi) |
| Wiring method |
Lead wire connection |
| Ambient Temperature |
-20~40°C |
| Storage Temperature |
-20~70°C |
| Ambient Humidity |
45~85% RH |
| Insulation resistance |
100MΩ min. at 500VDC |
| Certificate/Compliance |
CE, RoSH |
| Vibration resistnace |
UL1007 / 22AWG |
| Degree of protectione |
IP65 (Audible alarm type: IP52) |
| Weight (AC + Buzzer type) |
MS66M – 168g |
| MS66G – 180g |
| MS66P – 168g |
